Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ILM
  • Model Number: ILM-LCC056
  • Output Power: 1 - 50W
  • Output Type: Single
  • Input Voltage: 90-250VAC
  • Output Voltage: 30~36VDC
  • Output Frequency: 50/60HZ
  • Output Current: 900mA
  • waterproof LED driver: 35W
  • constant current LED driver: 900mA
  • IP68 LED driver: 35W

Packaging & Delivery

Packaging Details Double-corrugated bulk carton
1. Universal AV input with full range:90VAC~260VAC
2.Built-in active PFC fuction, PFC≥0.95
3.Comply with IP67, EMC standard
4.Fully encapsulated aluminum housing, suitable for wet, dry, damp locations
5.Protection: Over voltage, Over load, Over temperature, Short circuit
6.High efficiency (87%~88%)
7.Compliant to worldwide safety regulations for lighting
8.Long life span: 50000hrs
9.100% burn-in tests (at full load), full-round tests.
10. 3 years warranty
11. Rated output can be customized

Model
ILMLCC-056
DC Current
900mA
DC Voltage
30~36VDC
Rated Power
35W
Input Voltage
90~130VAC / 170~250VAC / 100~250VAC
Over Voltage Protection
130%
Over Power Protection
130%
Active PFC
0.95
EMC
EN55015: 2007 / EN61547: 1995+A1: 2000 / EN61000-3-2, EN61000-3-3: 2008
Efficiency
89%
Life Span
50000hrs
MTBF
250Khrs
Withstand Voltage
I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
Working Temperature
-35~+70°C
Size
100*35*25mm
Packing
0.5Kg/pcs, 24pcs/CTN

.Suitable for LED electronic display screen, LED street lights, LED tunnel lights, LED bridge lights, LED panel lights, LED ceiling lights, moving sign application, etc
